MAX710
Modular lowbed semi-trailer with 6–8 pendle axles, detachable front bogie, and excavator-style platform or with side beams
Compact strength. Exceptional as standard.
MAX710 is the modular lowbed semi-trailer with which MAX Trailer expands its range in the high payload segment. Vehicles with 6 to 8 pendle axles set new standards for efficiency and value for money. Remarkably compact, powerful, and optimized for weight. MAX710 consists of a gooseneck, a detachable front bogie with 2 or 3 axles, a lowbed platform—either excavator-style or with side beams—and a rear bogie with 4 or 5 axles. The gooseneck offers a technical fifth-wheel load of 38 tonnes.
The new vehicle for high payloads
Highlights
- 6–8 pendle axles for high payloads in construction and heavy haulage
- Detachable front bogie with 2 or 3 axles, impressively compact
- Lowbed platform available as excavator-style (with adjustable outriggers) or with side beams and fixed floor
- Rear bogie with 4 or 5 axles and new, more compact kingpin coupling for extra length gains
- Detachable gooseneck with a technical fifth-wheel load of 38 tonnes, enabling easy front loading
- Standard width 2,850 mm, optimized for heavy and industrial transport
Technical data
Vehicle type: Modular lowbed semi-trailer (pendle)
Axle configuration: 6–8 pendle axles (2+4, 2+5, 3+4, or 3+5)
Front bogie: Detachable, 2 or 3 axles
Rear bogie: 4 or 5 axles, kingpin coupling
Tyres: 19.5"
Suspension: Air
Standard width: 2,850 mm
Fifth-wheel load (gooseneck): 38 tonnes (technical)
Lowbed platform: Excavator-style with adjustable outriggers / Side beams with fixed floor
Applications: Construction, heavy and industrial transport, crane equipment, road service
